M5Stack NCIR Unit – MLX90614 Infrared Thermometer | U028

M5Stack NCIR Unit – MLX90614 Infrared Thermometer | U028

LB-M5-U028

Out of stock
$29.90 USD
$29.90 USD $19.95 USD
Sold out

Key Features

  • MLX90614ESF-AAA infrared sensor
  • Non-contact object and ambient temperature
  • Object range reference of -70 to 380 °C
  • Wide 90° field of view
  • I2C communication at address 0x5A

The M5Stack NCIR Unit measures non-contact surface temperature for equipment monitoring, thermal experiments, hot-object checks, environmental logging, and interactive systems. Its MLX90614ESF-AAA infrared sensor reports object and local ambient temperature over I2C address 0x5A with a wide 90° field of view. The object result represents an average across the viewed area rather than a single point. Useful accuracy depends on emissivity, distance, reflective surroundings, airflow, thermal stability, and optical cleanliness.

NCIR Unit: Core Functions and Control

Read Object and Ambient Temperature

The MLX90614 provides separate digital values for the viewed surface and the sensor’s local ambient temperature.

Understand the Wide 90° Field of View

The target must fill enough of the viewing cone to prevent backgrounds or nearby surfaces from dominating the result.

Account for Emissivity and Reflections

Polished metal, glass, and reflective coatings can behave differently from dark matte targets and require application-specific validation.

NCIR Unit Applications

  • Equipment surface-temperature monitoring
  • Motor and electrical-cabinet trending
  • Hot-object and process checks
  • Thermal presence experiments
  • Laboratory infrared measurement

How to Integrate the NCIR Unit

  1. Mount the sensor with an unobstructed view and keep the optical opening clean.
  2. Connect it to an I2C port and confirm that address 0x5A is available.
  3. Allow the sensor and enclosure to reach thermal stability.
  4. Test the actual target at the intended distance and angle against a suitable reference.
  5. Log object and ambient temperature and use persistence before alarms.

NCIR Unit Deployment Notes

  • The 90° field of view averages a broad area.
  • Emissivity, reflective backgrounds, angle, airflow, and enclosure heat affect readings.
  • Infrared sensing reports surface temperature, not internal or core temperature.
  • The full range does not provide identical accuracy under every condition.
  • This unit is not a certified medical thermometer or life-safety sensor.
